37D1837 - BMC Cylinder liner (100mm)

Need it delivering elsewhere? Click here

---

37D1837 Cylinder Liner (100mm) for BMC 2.8, 3.8 and 5.7 Diesel Engines

Quality replacement cylinder liner suitable for BMC 2.8, 3.8 and 5.7 diesel engines fitted to Nuffield tractors and other classic British agricultural and industrial machinery.

This engine liner is manufactured for reliable fit, sealing and long service life during engine rebuild and restoration work.

Technical specifications:

• Bore size: 99.92mm (3.934”)
• Flange diameter: 114.2mm (4.496”)
• Flange height: 11.17mm (0.440”)
• Outside diameter at liner seal contact area: 110.60mm (4.354”)
• Overall height: 221.5mm (8.720”)

Associated engine parts:

• Piston: 37D426
• Piston rings: AHM9025

Liner shims available:

• 89J88 – 0.003”
• 89J89 – 0.004”
• 89J90 – 0.005”

Liner seal required:

• 37D1857 (not included with liner)

Features:

• Quality replacement wet cylinder liner
• Suitable for BMC diesel engines
• Manufactured for reliable fit and sealing performance
• Ideal for engine overhaul and rebuild work
• Suitable for vintage tractor restoration projects

Important:

Always check liner dimensions and engine specifications carefully before ordering.

If you are unsure which liner is fitted to your engine, please contact us and we will be happy to help identify the correct parts for your tractor or engine rebuild.

Suitable for customers searching for BMC engine liners, Nuffield tractor engine parts, cylinder liners, wet liners, vintage diesel engine rebuild parts, tractor engine overhaul parts and replacement agricultural engine components.

We specialise in quality parts for Nuffield, Leyland and Marshall tractors and aim to supply reliable tractor spare parts that fit correctly and perform reliably.
