86K1190 - Cylinder liner (100mm)

Need it delivering elsewhere? Click here

86K1190 - Engine cylinder liner for BMC 2.8 and 3.8 engines

Bore size 99.92mm
Flange diameter 116.94mm
Flange height 8.90mm
Outside diameter where the liner seal contacts the liner 110.60mm
Overall height: 221.46

Note: use the following liner shims for this liner

89J88 (0.003")
89J89 (0.004")
89J90 (0.005")

Note: fit with liner seal part no 37D1857 (not included with liner)

Piston - 37D426
Piston Ring Set - AHM9025

Original equipment manufacturers names and parts numbers are quoted for reference purposes only and are not intended to suggest that our replacement parts are made by the original equipment manufacturer.
