BMK1032 - Starter motor

Need it delivering elsewhere? Click here

---

BMK1032 Nuffield tractor starter motor.

This is a new starter motor for selected Nuffield tractors fitted with the key start type starter motor.

Important fitment checks:

Please check the starter motor arrangement before ordering. The hole diameter in the bell housing must be 92mm, and this starter motor has 11 teeth.

BMK1032 was fitted as standard to Nuffield 10/42 and 10/60 tractors. It was also available as an optional fitment on earlier Nuffield models, so these must be checked before ordering.

Fitted to the following tractors:

• Nuffield 3DL, optional fitment - check before ordering
• Nuffield 4DM, optional fitment - check before ordering
• Nuffield 3/42, optional fitment - check before ordering
• Nuffield 4/60, optional fitment - check before ordering
• Nuffield 10/42, fitted as standard
• Nuffield 10/60, fitted as standard

Reference part numbers:

• Old Nuffield part number: BMK397
• Replaces Lucas part number: 26169

Important weather note:

This design of starter motor will not stand a lot of water exposure and is prone to water ingress if tractors are left outside. Where possible, protect the tractor from heavy rain and water exposure to help prolong starter motor life.
