Quality replacement engine liner suitable for BMC 2.6, 3.4T, 3.4TA and 5.1 diesel engines fitted to many Nuffield and Leyland tractors. Manufactured to the correct specification for reliable engine rebuilding, overhaul and restoration work on classic British tractors from the 1950s through to the 1980s.
• Bore size: 95.02mm (3.741")
• Flange diameter: 114.09mm (4.492")
• Flange height: 11.18mm (0.440")
• Outside diameter where the liner seal contacts the liner seal: 106.40mm (4.189")
• Overall height: 221.55mm (8.722")
Recommended related parts:
• Liner shim – AMK1970 (0.003")
• Liner seal – AMK61 (not included with liner)
• Piston and ring set – 37D976 Â
• Piston rings only – AHM9023Â
Suitable for BMC diesel engines fitted to various:
• Nuffield tractors
• Leyland tractors
• Marshall tractors using BMC-based engines
Commonly used during engine rebuilds, restoration projects and major overhauls.
Always check liner dimensions before ordering, as different engine variations were produced. If you are unsure about suitability for your tractor or engine, please contact us before purchasing and we will be happy to advise.
We specialise in quality parts for Nuffield, Leyland and Marshall tractors, including genuine old stock, reproduction and hard-to-find replacement parts.
Original equipment manufacturers names and parts numbers are quoted for reference purposes only and are not intended to suggest that our replacement parts are made by the original equipment manufacturer.
Product images are for illustrative purposes only and may not always be an exact representation of the product.
Important always check liner sizes before ordering,
if unsure please ring us for advice.
